TEST POINT (SMT)
Test Point For Auto-Insertion (3.2X1.6 Type)
[HK-2 Series] (1000pcs/reel)
PAT
In the case of reflowing by cream solder, recommended mounting pad layout should be more than 1.6x3.2 to strengthen the bonding.
Material
Brass
Finish
HK-2-G
Au plating over Ni
HK-2-S
Sn plating over Ni
Recommended land diameter
